Quality Output

Quality Output

Usage: Host system can monitor scanning performance (printing process, scan-
ning environment changes, etc.) by setting thresholds in their processing
or displaying the outputs for visual verification. For example, a certain
symbol that has been averaging 00100 reads per read cycle suddenly
drops to 00012, this would be a good indication that a problem has arisen
even though good reads are still occurring.
Definition: Allows the host to track the number of good reads per trigger by append-
ing a five digit numeric field to the end of bar code symbol data.
Quality Output Separator
Serial Cmd: KJquality output
<
Default: , (comma)
Options: any ASCII character
Note: If Quality Output Separator has been changed to any other character and you
want to re-define the separator as a comma, you will need to define it in the embedded
menu or default the scanner by a <Zd> command.
Note: For all serial configuration commands, the following characters cannot be
used: < > NUL
Reads/Trigger Status
Definition: When enabled, bar code data is followed by a separator, followed by the
five digits in the form of 00000.
Serial Cmd: KJquality output
<
Default: Disabled
Options: 0 = Disabled
MS-820 Industrial Bar Code Scanner User's Manual
6-20
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
separator,reads/trigger status>
separator,reads/trigger status>
1 = Enabled
