Master Database

Important: Master Database is used only for comparing entire symbols, when
Sequential and Wild Card are NOT enabled, and Start Position is equal to 0.
Master Database Overview
Usage: Used where more than one master symbol is required, as in a Multisym-
bol setup, for matching and other matchcode operations.
Definition: Allows you to define up to 10 master symbols as the master symbol data-
base, which can be entered by keyboard, scanned in, displayed, or
deleted by serial or ESP commands.
Set master
symbol data-
base size here.
Double-click row to enter Loads the scanner's
data into popup dialog box. saved master symbols
into ESP.
Master Symbol Database Size
Definition: Master Symbol Database Size allows you to select 1 to 10 master
symbols for the master symbol database.
ESP: First set the number of master symbols you want to include by using
Master Symbol Database Size
Serial Cmd: <KMmaster symbol database
Default: 1
Options: 1 to 10
MS-820 Industrial Bar Code Scanner User's Manual
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Chapter 11 Utilities
Loads the next
symbol scanned
into selected
index.
Saves the displayed data-
base to the scanner.
and entering the number.
size>
