C 5:
HAPTER ADDING DEVICES AND DEVICE

Discover Devices

Use this command to initiate a search for all devices on your system. The search will
automatically detect all newly attached, and previously existing Raritan devices on your network,
including Paragon, P2-SC, IP-Reach, Dominion KX, Dominion KSX units, IPMI servers, and
CC-SGs. After locating the devices, you may connect them to your CC-SG system if they are not
already connected.
Note: iLO/RILOE devices and Generic devices, such as hubs, Windows servers, Cisco routers,
cannot be discovered. They have to be manually added.
1. Click on the Devices tab.
2. On the Devices menu, click Discover Devices. The Discover Devices screen appears.
3. Type the range of IP addresses where you expect to find the devices in the From Address
and To Address fields. The To Address should be larger than the From Address. Specify a
mask to apply to the range.
255.255.255.255 is sent, which broadcasts to all local networks. To discover devices across
subnets, you must specify a mask.
4. Click Broadcast discovery if searching for devices on the same subnet on which CC-SG
resides. Uncheck Broadcast discovery to discover devices across all subnets.
5. To search for a particular type of device, highlight it in the list of Device types. By default,
ALL device types are highlighted. Use Ctrl+click to select one or more device types.
6. Click OK to start the search, or Cancel to exit without searching, or Stop to discontinue the
discovery process. Discovered devices appear in a Discover Devices list.
G
ROUPS

Figure 79 Discover Devices Screen

If a mask is not specified, then a broadcast address of

Figure 80 Discovered Devices List Window

67
