C 2: A
HAPTER CCESSING

Main Window Components

Menu Bar
(Operation and
Configuration
commands)
Toolbar
(shortcuts for
)
commands
Selection tabs
(Ports, Users,
and Devices)
Selection tree
(expandable /
collapsible
using + and –
signs)
The CC-SG menu bar displays all operations and configuration commands. Active commands are
based upon the privileges of the user, as established by the CC-SG Administrator. The user's
privileges also determine the ports and devices that appear in the Ports and Devices trees.
Clicking on the Ports tab displays the Ports selection tree, clicking on the Users tab displays the
Users selection tree, and clicking on the Devices tab displays the Devices selection tree. Expand
and collapse these trees by clicking on the + and – buttons in front of the icons to view all or a
specific set of Ports, Users, or Devices. Users can arrange listed ports by name or status by right-
clicking on the tree and selecting the desired Port Sorting Option.
Administrators must configure Ports, Users, and Devices in the CC-SG system upon setup and
before executing any commands. Please see Appendix C: Initial Setup Process Overview for an
overview of this process.
Note: The Quick Commands toolbar has been upgraded to include "Back" and "Forward"
buttons, the left and right-pointing arrows. Please use these as you would use the Back and
Forward commands in your Internet browser. The Back
last screen you viewed, and the Forward
viewed, after you have used the Back command.
CC-SG

Figure 13 CC-SG Application Window

Screen Display Area
arrow button will return you to the
button moves you forward to the next screen you
15
