Chapter 12: Advanced Administration

Configuration Manager

Network Configuration

1. On the Setup menu, click Configuration Manager. When the Configuration Manager
screen appears, click on the Network Setup tab.

Figure 192 Configuration Manager Network Settings Screen

2. Type the CC-SG hostname in the Host Name field. For hostname rules, see
Terminology/Acronyms in Chapter 1: Introduction. Once Update Configuration is
selected, the field will be updated to reflect the Fully-Qualified Domain Name (FQDN) if
a domain server and domain suffix has been configured.
3. Click either Primary/Backup Mode or Active/Active Mode. A standard CC-SG
provides two Network Interface Controllers (NIC)s. The NICSs (labeled left-to-right
from the rear) are as follows:
M
ODEL
G1
V1
One interface could be used by itself or both could be used simultaneously. For simplicity,
the discussion below uses LAN1 as the left-most NIC (primary) and LAN2 as the right-
most NIC. Some internal diagnostics and messages may refer to these interfaces as
"eth0" and "eth1".
Note: If both interfaces are disconnected, CC-SG restarts.
L - NIC (
EFT MOST PRIMARY INTERFACE
LAN1
LAN1
) R - NIC
IGHT MOST
LAN0
LAN2
161
