Modem Configuration

Use this screen to access CC-SG from a client machine over a dial-up connection. This method of
accessing CC-SG can be used in emergency situations.
Note: A modem is not available and cannot be configured on the V1 platform.
Configure CC-SG
1. On the Setup menu, click Configuration Manager. When the Configuration Manager screen
appears, click on the Modem tab.
2. Type the Server Address, that is, the IP address of the CC-SG.
3. Type the Client Address, that is, the IP address of the client that will dial into CC-SG.
4. Type the Client Phone, that is, if using call-back dialing this is the call-back number that
CC-SG dials to connect to the client.
5. Click Update Configuration to save the modem information to the system.
6. Click Close to close the Configuration Manager screen.
Configure the Modem on Client PC
Connect a phone line to the CC-SG, which has a built-in modem. Optionally, remove the LAN
cables.
On the client that will be dialing in, connect a modem to the client machine, for example, a
Windows XP machine. Connect a phone line to the client modem. Restart the client machine and
the connected modem is discovered as new hardware. Install the modem on the client as follows,
which assumes a Windows XP client machine:
1. Select Control Panel
2. Click on the Modems tab.

3. Click Properties.

C
OMMAND

Figure 198 Configuration Manager Modem Screen

Phone and Modem Options.

Figure 199 Modems Tab
