Device Power Manager

Before using the Device Power Manager view, make a physical connection of a PowerStrip to a
Dominion SX or Dominion KSX unit. When you add the PowerStrip device, define this
connection in CC-SG. Once the PowerStrip is added, you can associate it with the Dominion SX
serial ports or with Dominion KSX dedicated power ports. The Device Power Manager view
displays outlets connected to devices' ports and allows you to remotely power on or power off
associated ports, as well as monitor power, voltage, current, and temperature of the device.
In the Devices tree, select a device, then on the Devices menu, click Device Power Manager.
1.
The Device Power Manager screen appears.
The outlets will be listed in the Outlets Status panel. You may have to scroll to view all
2.
outlets.
Click the On or Off radio buttons for each outlet to power ON or power OFF the outlet.
3.
Click Recycle to restart the device connected to the outlet.
4.
Click Close to close the Device Power Manager screen.
5.
Repeat steps 1 through 5 to monitor and control other devices.
6.
Note: CC-SG automatically recognizes the outlets of PowerStrips attached to Dominion KX and
P2-SC devices as additional ports of those devices; no PowerStrip association is necessary.
These outlets are added and configured the same as any other device port. See section Port
Manager in Chapter 6: Configuring Ports and Port Groups for instructions on adding and
editing ports.
C C
OMMAND ENTER

Figure 78 Device Power Manager Screen
