Raritan Command Center CC-SG Administrator's Manual page 264

248
Q
UESTION
to add a console/serial port
to CC-SG?
Which version of Java will
Raritan's CC-SG be
supporting?
An administrator added a
new port to the CC-SG
database and assigned it to
me, how can I see it in my
Ports tree?
How will the Windows
desktop be supported in the
future?
What are some design
guidelines for large-scale
systems - any constraints or
assumptions?
Authentication
How many user accounts
can be created for CC-SG?
Can I assign specific port
access to a specific user?
C C
OMMAND ENTER
the following conditions are met:
- The Dominion unit is active.
- The Dominion unit has not reached the maximum number of
configured user accounts.
The earliest version CC-SG will support will be at least the Java
2 platform. Users must download the Java 2 plug-in if using IE.
By default, Netscape will use Sun JVM.
For server and client side minimum Java requirements, please
see the Compatibility Matrix on http://www.raritan.com/support.
Click Firmware Upgrades and then CommandCenter.
To update the tree and see the newly assigned port, click on the
Refresh shortcut button on the toolbar. Remember that
refreshing CC-SG will close all of your current console sessions.
Accessing CC-SG from outside the firewall can be achieved by
configuring the right ports on the firewall. The following ports
are standard ports:
80: for HTTP access via Web browser
443: for HTTPS access via Web browser
8080: for CC-SG server operations
2400: for Proxy mode connections
5001: for IPR/DKSX/DKX/ P2-SC event notification
If there is firewall between two cluster nodes, the following
ports should be opened for cluster to be worked properly:
8732: for cluster nodes heartbeat
5432: for cluster nodes DB replication
Raritan provides two models for server scalability: the data-
center model and the network model.
The data center model uses Paragon to scale to thousands of
systems in a single data center. This is the most effective and
cost-efficient way to scale a single location. It also supports the
network model with IP-Reach and the IP User Station (UST-IP).
The network model scales through use of the TCP/IP network
and aggregates access through CC-SG, so users don't have to
know IP addresses or the topology of access devices. It also
provides the convenience of single sign-on.
Check your licensing restrictions. There is no specified limit to
the number of user accounts that can be created for CC-SG, but
the number is not limitless. The size of the database, the
performance of the processor, and the amount of memory on the
hosting server will determine how many user accounts can
actually be created. These user accounts can be any combination
of Administrators and Operators with at least one Administrator
account.
Yes, if you have Administrator permissions. Administrators
have the ability to assign specific ports per user.
S G A
ECURE ATEWAY DMINISTRATOR
A
NSWER
G
UIDE
