MVI69-101M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-101 Master Communication Module
CD-ROM drive
HyperTerminal or other terminal emulator program capable of file transfers
using Zmodem protocol.
1.2
Package Contents
The following components are included with your MVI69-101M module, and are
all required for installation and configuration.
Important: Before beginning the installation, please verify that all of the following items are
present.
Qty.
Part Name
1
MVI69-101M
Module
1
Cable
3
Cable
2
Adapter
1
ProSoft
Solutions
CD
If any of these components are missing, please contact ProSoft Technology
Support for replacement parts.
Page 8 of 133
Part Number
Part Description
MVI69-101M
IEC 60870-5-101 Master Communication Module
Cable #15, RS232
For RS232 Connection to the CFG Port
Null Modem
Cable #14, RJ45 to
For DB9 Connection to Module's Port
DB9 Male Adapter
cable
1454-9F
Two Adapters, DB9 Female to Screw Terminal.
For RS422 or RS485 Connections to Port 1 and 2
of the Module
Contains sample programs, utilities and
documentation for the MVI69-101M module.
Start Here
ProSoft Technology, Inc.
February 4, 2008
