Reference
Word Offset in Block
4
5
6
7
8 to n
where n = 60, 120, or 240 depending on the Block Transfer Size parameter (refer
to the configuration file).
The module does not send a response block to the processor after receiving this
block.
Warm Boot Block (9998)
Block 9998 performs a warm-boot operation on the module. The format of the
block constructed by the processor is as follows:
Offset
0
1 to 247
In this version of the module, the warm and cold boot processes perform the
same operation as many of the variables that must be initialized are fixed when
the module first boots and cannot be changed after the application starts.
Cold Boot Block (9999)
Block 9999 performs a cold-boot operation on the module. The format of the
block constructed by the processor is as follows:
Offset
0
1 to 247
In this version of the module, the warm and cold boot processes perform the
same operation as many of the variables that must be initialized are fixed when
the module first boots and cannot be changed after the application starts.
ProSoft Technology, Inc.
February 4, 2008
MVI69-101M ♦ CompactLogix or MicroLogix Platform
Data Field(s) Description
Hour This field contains the hour value for the new time.
Valid entry for this field is in the range of 0 to 23.
Minute This field contains the minute value for the new time.
Valid entry for this field is in the range of 0 to 59.
Seconds This field contains the second value for the new
time. Valid entry for this field is in the range of 0 to
59.
Milliseconds This field contains the millisecond value for the new
time. Valid entry for this field is in the range of 0 to
999.
Not Used Not Used
Description
9998
Spare
Description
9999
Spare
IEC 60870-5-101 Master Communication Module
Length
1
247
Length
1
247
