Point Index
Point Index field specifies the address in the remote slave device of the point to
interact with.

2.4.7 Qualifier Parameter

The Qualifier Parameter field defined for a command is dependent on the data
type used in the command. In order to compute the qualifier for a command, add
all the values for the features to use with a command together to form a single
number. This number should be entered in the command record. Each data set is
discussed below:
Single Point, Double Point, and Regulating Setup
The format of the field for Single Point (45), Double Point (46), and Regulating
Step (47) commands is as follows:
Single Point, Double Point and Regulating Step Point Commands
Bit Single
0 Value
1 0
2
3
4
5
6
7
8
9
10
to
15
The value field for the different data types can be derived from the module's
database or that set in the command. The User Override bit is utilized to select
the source of the data value. The values for each data type are defined below:
Page 40 of 133
Description
Parameter, normalized measured value
Parameter, scaled measured value
Parameter, short float value
Parameter activation command
BCD integrated setpoint command
Send a class 2 poll
Double Step
Control Control
Value Value
Qualifier Code
Select/Execute Code
Deselect Code
Use Override Value
Not Utilized
Module Configuration with RSLogix
DB Index type
Word address
Word address
Double-word address
NA
3 word address
NA
