MVI69-101M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-101 Master Communication Module
Pass-Through Events
Y or N (N = Default)
This parameter specifies if event messages received on the master ports will be
passed to the processor. If the parameter is set to N, event messages will not be
passed to the processor. If the parameter is set to Y, the module will pass all
events received to the processor using block identifier 9903.
Block Transfer Size
60, 120 or 240
This read-only parameter specifies the number of words in each block transferred
between the module and processor. Valid values for this parameter are 60, 120
and 240.

2.4.2 [IEC-870-5-101 Master]

This is the configuration for the IEC-870-5-101 master port emulated on the
module.
Session Count
1 to 32
This parameter specifies the maximum number of session to establish on the
module. This corresponds to the number of slaves to be interfaced with the
module. This value represents the total number of slaves on both ports
combined.

2.4.3 [IEC-870-5-101 Master Port x]

Baud Rate
This parameter specifies the baud rate to be used on the communication channel
(port). Values from 110 to 38.4K are permitted.
Parity
None, Odd, Even
This parameter specifies the parity for this port using the following code
definitions: N=none, O=odd, E=even.
RTS On
0 to 65535
The parameter sets the RTS pre-send delay. The value entered represents the
number of milliseconds the module will wait after setting the RTS modem line
before sending the data.
