Reference
⌧ Direct command transmission
command
⌧ Direct set point command transmission
point cmd
⌧ No additional definition
⌧ Short pulse duration (duration determined by a system parameter in the
outstation)
⌧ Long pulse duration (duration determined by a system parameter in the
outstation)
⌧ Persistent output
Transmission of Integrated totals
(station- or object-specific parameter)
⌧ Counter request
⌧ Counter freeze without reset ⌧
⌧ Counter freeze with reset
⌧ Counter reset ⌧
Addresses per group have to be defined
Parameter loading
(object-specific parameter)
Threshold value
⌧
⌧ Smoothing factor
⌧ Low limit for transmission of measured value
⌧ High limit for transmission of measured value
Parameter activation
(object-specific parameter)
⌧ Act/deact of persistent cyclic or periodic transmission of the addressed
object
File transfer
(station-specific parameter)
File transfer in monitor direction
File transfer in control direction
ProSoft Technology, Inc.
February 4, 2008
MVI69-101M ♦ CompactLogix or MicroLogix Platform
⌧ C_SE_ACTTERM used
⌧
Request counter group 3
⌧ Request counter group 4
IEC 60870-5-101 Master Communication Module
⌧ Select and execute
⌧
General request counter
Request counter group 1
⌧ Request counter group 2
Select/execute set
