Module Configuration with RSLogix
If the Poll Interval time is set, the command will be executed, when the interval
timer expires. If the parameter is set to 2, the command will execute only if the
internal data associated with the command changes. This value is valid only for
write commands.
Database Index
Database Index is the location in the module's database to use as the source for
the data in the command. The
of the index.
Poll Interval
This parameter specifies the minimum frequency at which the module should
execute the command. The value is entered in units of seconds. For example, to
execute a command every 10 seconds, enter a value of 10 in the field. A value of
0 for the parameter implies that the command should be executed every scan of
the list.
Session Index
Session Index represents the session index in the module to associate with the
command. This index is set when the session is read in from this file. The range
of values for this field is 0 to 31.
Sector Index
Sector Index represents the sector index for the specific session. The range of
values for this field is 0 to 4.
Data Type
Data type file represents the ASDU type as follows:
Type
45
46
47
48
49
50
51
100
101
102
103
104
105
107
ProSoft Technology, Inc.
February 4, 2008
MVI69-101M ♦ CompactLogix or MicroLogix Platform
data type
Description
Single point command
Double point command
Regulating Step point command
Setpoint, normalized point command
Setpoint, scaled point command
Setpoint, short float point command
Bitstring (32-bits) point command
Group interrogation command
Counter interrogation command
Read command
Clock Synchronization
Test command (101 standard)
Reset process command
Test command (104 standard)
IEC 60870-5-101 Master Communication Module
(page 39) field determines the meaning
DB Index type
Bit address
Bit address
Byte address
Word address
Word address
Double-word address
Double-word address
NA
NA
NA
NA
NA
NA
NA
