Reference

5 Reference
In This Chapter
Product Specifications ........................................................................... 79
Functional Overview.............................................................................. 81
Master Driver......................................................................................... 96
Cable Connections ................................................................................ 97
MVI69-101M Status Data Area............................................................ 103
MVI69-101M Configuration Data Definition ......................................... 107
Database Form.................................................................................... 112
Command List Form ............................................................................ 113
Interoperability..................................................................................... 114
5.1

Product Specifications

The MVI69 IEC 60870-5-101 Master Communication Module allows
CompactLogix and MicroLogix I/O compatible processors to interface easily with
IEC 60870-5-101 master (controlled unit) devices.

5.1.1 Features and Benefits

The MVI69-101M module interfaces up to 32 serial communication devices with
the CompactLogix processor. Two communication ports on the module act as
controlling devices (masters) to interface with controlled devices on their own
networks. Each port is individually configurable and can be set for balanced or
unbalanced mode. Data is exchanged between the serial network and the
CompactLogix processor using the internal database contained in the module
and direct control by the processors ladder logic.

5.1.2 General Specifications

Single Slot - 1769 backplane compatible
The module is recognized as an Input/Output module and has access to
processor memory for data transfer between processor and module
Ladder Logic is used for data transfer between module and processor.
Sample ladder file included.
Configuration data obtained from configuration text file downloaded to
module. Sample configuration file included.
Supports all CompactLogix processors: L20/L30/L31/L32/L35, L43 and L45
(L43 and L45 supported with RSLogix 5000 v16.03 or later)
Also supports MicroLogix 1500 LRP
