5.5.2 MVI69-IEC 60870-5-101 Master Communication Module Error
Codes
Error Description
51 Physical layer error - Error transmitting message
52 Physical layer error - Intercharacter timeout occurred before message fully received.
53 Physical layer error - Frame not entirely received before timeout condition.
54 Physical layer error - Invalid frame length.
101 Link layer error - Invalid checksum received
102 Link layer error - Address unknown to module
103 Link layer error - Link established
104 Link layer error - Link failed
105 Link layer error - Received primary
106 Link layer error - FCB error discard
107 Link layer error - FCB error repeat
108 Link layer error - Invalid start character received
109 Link layer error - Invalid second character received
110 Link layer error - Invalid ending character received
111 Link layer error - Length mismatch error
112 Link layer error - Illegal function
113 Link layer error - No confirmation received
114 Link layer error - No ACK received
115 Link layer error - Sequence unknown
116 Link layer error - Out of sequence
117 Link layer error - Remote close
118 Link layer error - Unexpected ACK
119 Link layer error - Request cancelled
201 Application layer error - Length mismatch
202 Application layer error - Address unknown
203 Application layer error - Response late
251 RBE error - Clock event buffer overflow
252 RBE error - Event buffer overflow
271 Data error - Address unknown
281 Control error - Illegal operation
282 Control error - Illegal value
283 Control error - Not selected
301 Initialization error - Database
302 Initialization error - Out of memory
401 Channel open error
501 Session error - Database
502 Session error - Configuration
601 No memory to receive message
602 Session not reserved
