Module Configuration with RSLogix
On the General page, fill in the values shown in the tables below, according to
the Block Transfer Size parameter in the configuration file. You must select the
Comm Format as Data - INT.
The configured Input Size and Output Size will depend on the block transfer size
parameter defined in the configuration file. Use the values in the table
corresponding with the block transfer size you configured.
Block Transfer Size = 60
Field
Type
Parent
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
Block Transfer Size = 120
Field
Type
Parent
Name
Description
Comm Format
Slot
Input Assembly Instance
Input Size
Output Assembly Instance
Output Size
Configuration Assembly Instance
Configuration Size
Block Transfer Size = 240
Field
Type
Parent
Name
Description
ProSoft Technology, Inc.
February 4, 2008
MVI69-101M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-101 Master Communication Module
Recommended Value
1769-MODULE Generic 1769 Module
Local
MVI69
MVI69 Application Module
Data - INT
The slot number in the rack where the module is installed
101
62
100
61
102
0
Recommended Value
1769-MODULE Generic 1769 Module
Local
MVI69
MVI69 Application Module
Data - INT
The slot number in the rack where the module is installed
101
122
100
121
102
0
Recommended Value
1769-MODULE Generic 1769 Module
Local
MVI69
MVI69 Application Module
