Reference
Offset Parameter
38 Cmd Err
39 Requests
40 Responses
41 Err Sent
42 Err Received
43 Cfg Err
44 Current Error
45 Last Error
The following table defines the contents of the configuration error word. Each bit
in the word corresponds to an error condition recognized when the module is
configured. There is a separate word for each application port. This data is
reported in the status data area previously defined.
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
The following table lists all potential errors that can be generated by the IEC
60870-5-101 master driver:
ProSoft Technology, Inc.
February 4, 2008
Description
This word contains the number of command errors recognized on
channel 1.
This word contains the total number of messages transmitted on
channel 1.
This word contains the total number of messages received on channel
1.
This word contains the number of error messages sent on channel 1.
This word contains the number of error messages received on channel
1.
This bit mapped word recognizes any configuration errors for channel
1. Refer to the configuration error word table for a definition of each bit.
This word contains the error code for the current command executing
on channel 1.
This word contains the error code for the last error recognized on
channel 1.
Code Description
0x0001 Invalid baud rate selected
0x0002 Invalid parity selected
0x0004 Received timeout set to 0
0x0008 Invalid Port selected for a session
0x0010 Invalid sector count for session
0x0020 Could not allocate memory for sector of a session.
0x0040 Invalid length data for session:
Data link length
Command address of ASDU length
Information object address length
COT octet count
0x0080 Invalid failure delay or confirm timeout for session.
0x0100
0x0200
0x0400
0x0800
0x1000
0x2000
0x4000
0x8000
