Module Configuration with RSLogix
5 to 31 = Reserved by standard
32 to 63 = Reserved for special use (private range)
Local parameter change:
0=No change
64=Change Parameter in operation:
0=Operation
128=Not in operation
Parameter Activation
The format of this field for the Parameter Activation (113) is as follows:
No database value used with the construction of this command.
The Qualifier Parameter used with the command is determined by summing the
options from the lists that follow:
Parameter Qualifier:
0=Not used
1=Act/Deact of previously loaded parameters (point index = 0)
2=Act/Deact of the parameter of the point index specified
3=Act/Deact of persistent cyclic or periodic transmission of the addressed
object
4 to 127 = Reserved by standard
128 to 255 = Reserved for special use (private range)
Activation Qualifier:
0=Deactivate
256=Activate
ProSoft Technology, Inc.
February 4, 2008
MVI69-101M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-101 Master Communication Module
Parameter Activation Command
Bit Description
0
to Parameter Qualifier
7
8 Activation Qualifier
9
to Not Utilized
15
