Module Configuration with RSLogix
Read Command
The format of this field for the Read (102) command is as follows:
No database value is associated with the construction of this command and no
qualifier value is used in this release of the software.
Clock Synchronization
The format of this field for the Clock Synchronization (103) command is as
follows:
No database value is associated with the construction of this command.
The Qualifier Parameter for this command has one of the following values:
0=Clock synchronization with out delay utilized
1=Synchronize clock with delay set
2=Measure delay, load delay then synchronize clock
Test Command
The format of this field for the test command (104 and 107) is as follows:
Test Command (both 101 and 104 versions)
No database value is associated with the construction of this command and no
qualifier value is used in this release of the software.
