MVI69-101M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-101 Master Communication Module
Configuration/Error Status Flags (CfgErr)
The Configuration_Error word member of the MVI69101M_ChannelStatus
reports configuration errors for the respective server. If the module is not
functioning as expected, inspect the value presented in this object. If a
configuration error exists, the associated bit will be set. A value of zero for the bit
indicates the configuration value is valid. This does not guarantee that the
module is configured correctly for your application. The bits used by this member
are shown in the following table:
Bit
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Backplane Object (MVI69101M_UTIL)
The MVI69101M_UTIL object stores all the variables required for the data
transfer operation between the module and the controller. The LastRead data
member is used as the handshaking byte to indicate the arrival of new data from
the module. The structure of this object is shown in the following illustration:
Name
Warmboot
ColdBoot
BPLastRead
BPLastWrite
BlockIndex
BootTimer
LoopIndex
BlockTransferSize
The other members of the object are be utilized in the ladder logic to assist in the
data transfer operation.
Page 28 of 133
Code Description
0x0001 Invalid baud rate selected
0x0002 Invalid parity selected
0x0004 Received timeout set to 0
0x0008 Invalid Port selected for a session
0x0010 Invalid sector count for session
0x0020 Could not allocate memory for sector of a session.
Invalid length data for session: Data link length Command
0x0040
address of ASDU length Information object address length COT
octet count
0x0080 Invalid failure delay or confirm timeout for session.
0x0100
0x0200
0x0400
0x0800
0x1000
0x2000
0x4000
0x8000
Data Type Description
BOOL Requests warmboot of the module
BOOL Requests coldboot of the module
INT Index of last read
INT Index of last write
INT Computed block offset for data table
TIMER Used to clear output block ID after power up
INT Used as index during Loops
INT Must match the configuration parameter Block Transfer (60,
120, 240). This value must be set in ladder by the user
Module Configuration with RSLogix
