Reference
Error Description
603 Illegal session
604 Session is reserved
605 Session is not available
701 No memory to transmit message
702 ASDU not supported
703 Duplicate request
704 Illegal sector
705 Control mode is illegal
801 Partial stop request
802 Stop request failed
901 Response timeout
902 Negative COT in response
903 Session is offline
904 Session is disabled
905 Select confirmation received, waiting to execute
906 Execute confirmation has not be received
5.6

MVI69-101M Configuration Data Definition

This section contains a listing of the parameters and their definitions for the
MVI69-101M module configuration file definition (IEC101M.CFG).
5.6.1 MVI69 IEC 60870-5-101 Master Communication Module
Configuration
[Section]/Item
[Backplane Configuration]
Module Name:
Write Register Start:
Write Register Count:
Read Register Start:
Read Register Count:
ProSoft Technology, Inc.
February 4, 2008
MVI69-101M ♦ CompactLogix or MicroLogix Platform
IEC 60870-5-101 Master Communication Module
Value Range Description
Backplane transfer parameters
0 to 80 This parameter assigns a name to the module that
characters can be viewed using the configuration/debug port.
Use this parameter to identify the module and the
configuration file.
0 to 3999 This parameter specifies the starting register in
the module where the data transferred from the
processor will be placed. Valid range for this
parameter is 0 to 3999.
0 to 4000 This parameter specifies the number of registers
to transfer from the processor to the module. Valid
entry for this parameter is 0 to 4000.
0 to 3999 This parameter specifies the starting register in
the module where data will be transferred from the
module to the processor. Valid range for this
parameter is 0 to 3999.
0 to 4000 This parameter specifies the number of registers
to be transferred from the module to the
processor. Valid entry for this parameter is 0 to
4000.
