1.6 Specifications

1.7 Typical Coverage

Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Specifications
Ethernet I/F
Protocol
Power Input
Audio Output
Line In:
Input Signal Amplitudes
Input Impedance
Line Out:
Output Signal Amplitudes
Output Level
Total Harmonic Distortion
Output Impedance
Operating Temperature
Payload Types
b
Dimensions
Boxed Weight
Part Number
Loudspeaker Part Number
a.When used with the 011068 Mini Horn.
b. Dimensions are measured from the perspective of the product being upright with the front of the
product facing you.
With one horn attached to Paging Amplifier under standard 802.3af PoE power, coverage is up to
5,000 square feet. With two horns attached to the Paging Amplifier under 802.3at PoE (high power),
coverage is up to 10,000 square feet depending on ambient background noise levels.
Table 1-1. Specifications
10/100 Mbps
SIP RFC 3261 Compatible
PoE 802.3at or 802.3af
802.3af - SPL 114 dB @ 1 meter
802.3at - SPL 117 dB @ 1 meter
2.0 VPP maximum
10k Ohm
2.0 VPP maximum
+2dBm nominal
0.5% maximum
10k Ohm
o o
-10 C to 50 C (14
G.711 a-law, G.711 u-law, and G.722
10 in. [254 mm] Length
4 in. [101.6 mm] Width
14 in. [355.6 mm] Height
6.5 lbs. [2.95 kg]
011405
011068
931236C
Product Overview
Specifications
a
a
o o
F to 122 F)
CyberData Corporation
5
