2.2.2 NEMA Box Components of the SIP Loudspeaker Amplifier (PoE)

Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Figure 2-5 shows all of the NEMA box components of the SIP Loudspeaker Amplifier (PoE).
Figure 2-5. Loudspeaker Amplifier Components—PoE
NEMA Box Components of the SIP Loudspeaker Amplifier (PoE)
931236C
SIP Loudspeaker Amplifier (PoE) Setup
RTFM Switch
Ethernet Connection
Speaker Connection
LEDs
Volume
CyberData Corporation
10
