CyberData 011405 Operation Manual page 48

Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
2. On the Network page, enter values for the parameters indicated in
Note The question mark icon (
after the Toggle Help button is pressed
Table 2-16. Network Configuration Parameters
Web Page Item
Stored Network Settings
Addressing Mode
Hostname
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
DHCP Timeout in seconds
Current Network Settings
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
VLAN Settings
VLAN ID (0-4095)
VLAN Priority (0-7)
) in the following table shows which web page items will be defined
.
Description
Select either DHCP IP Addressing or Static Addressing by marking
the appropriate radio button. DHCP Addressing mode is enabled on
default and the device will attempt to resolve network addressing with
the local DHCP server upon boot. If DHCP Addressing fails, the
device will revert to the last known IP address or the factory default
address if no prior DHCP lease was established. See
"Factory Default Settings" for factory default settings. Be sure to click
Save and Reboot to store changes when configuring a Static
address.
This is the hostname provided by the DHCP server. See the
DHCP/DNS server documentation for more information. Enter up to
64 characters.
Enter the Static IPv4 network address in dotted decimal notation.
Enter the Subnet Mask in dotted decimal notation.
Enter the Default Gateway IPv4 address in dotted decimal notation.
Enter the primary DNS Server IPv4 address in dotted decimal
notation.
Enter the secondary DNS Server IPv4 address in dotted decimal
notation.
Specify the desired time-out duration (in seconds) that the device will
wait for a response from the DHCP server before reverting back to
the stored static IP address. The stored static IP address may be the
last known IP address or the factory default address if no prior DHCP
lease was established. Enter up to 8 characters. A value of -1 will
retry forever.
Shows the current network settings.
Shows the current Static IP address.
Shows the current Subnet Mask address.
Shows the current Default Gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Specify the IEEE 802.1Q VLAN ID number. Enter up to 4 digits.
Note: The device supports 802.1Q VLAN tagging support. The
switch port connected to the device will need to be in "trunking mode"
for the VLAN tags to propagate.
Specify the IEEE 802.1p VLAN priority level. Enter 1 digit. A value of
0 may cause the VLAN ID tag to be ignored.
931236C
SIP Loudspeaker Amplifier (PoE) Setup
Configure the Network Parameters
Table 2-16.
Section 2.3.1,
CyberData Corporation
41
