3. On the Home page, review the setup details and navigation buttons described in
Note The question mark icon (
after the Toggle Help button is pressed
Web Page Item
Admin Settings
Username
Password
Confirm Password
Current Status
Serial Number
Mac Address
Firmware Version
IP Addressing
IP Address
Subnet Mask
Default Gateway
DNS Server 1
DNS Server 2
SIP Mode
Multicast Mode
Event Reporting
Nightringer
Primary SIP Server
Backup Server 1
Backup Server 2
Nightringer Server
Import Settings
Export Settings
) in the following table shows which web page items will be defined
.
Table 2-10. Home Page Overview
Description
The username to access the web interface. Enter up to 25 characters.
The password to access the web interface. Enter up to 25 characters.
Confirm the web interface password.
Shows the device serial number.
Shows the device Mac address.
Shows the current firmware version.
Shows the current IP addressing setting (DHCP or static).
Shows the current IP address.
Shows the current subnet mask address.
Shows the current default gateway address.
Shows the current DNS Server 1 address.
Shows the current DNS Server 2 address.
Shows the current status of the SIP mode.
Shows the current status of the Multicast mode.
Shows the current status of the Event Reporting mode.
Shows the current status of the Nightringer mode.
Shows the current status of the Primary SIP Server.
Shows the current status of Backup Server 1.
Shows the current status of Backup Server 2.
Shows the current status of Nightringer Server.
Use this button to select a configuration file to import.
After selecting a configuration file, click Import to import the
configuration from the selected file. Then, click Save and Reboot to
store changes.
Click Export to export the current configuration to a file.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
931236C
SIP Loudspeaker Amplifier (PoE) Setup
Log in to the Configuration Home Page
Table
CyberData Corporation
31
2-10.
