Web Page Item
Fast Fade
Slow Blink
Fast Blink
Multicast Call Color
Red
Green
Blue
2.3.8.1 Assigning Priority
Ringtones and
Nightringtones
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Table 2-20. Multicast Configuration Parameters (continued)
Note You must click on the Save button and then the Reboot button for the changes to take
effect.
The device will prioritize simultaneous audio streams according to their priority in the list.
If both SIP and Multicast is enabled, SIP audio streams are considered priority 4.5. SIP audio will
interrupt multicast streams with priority 0 through 4 and will be interrupted by multicast streams with
priority 5 through 9.
During priority 9 multicast streams, the volume is set to maximum.
Note SIP calls, multicast streams, ring tones, ringback tones, and nightring tones are all
prioritized.
Ringtones all play at the same priority level. This means that it is possible to have a nightring tone
and a normal ringtone playing at the same time.
Description
Strobe will increase in brightness from 0 to the specified
brightness and back to 0 over the course of about 1.5 seconds
during the duration of the event.
Strobe will blink ON at the specified brightness for one second
then OFF for one second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five
times per second during the duration of the event.
Select desired color (only one may be chosen).
The red LED value for Multicast.
The green LED value for Multicast.
The blue LED value for Multicast.
Use this button to preview the strobe flashing behavior for the
Multicast Strobe Settings.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of
some of the web page items. First click on the Toggle Help
button, and you will see a question mark (
some of the web page items. Move the mouse pointer to hover
over a question mark to see a short description of a specific web
page item.
931236C
SIP Loudspeaker Amplifier (PoE) Setup
Configure the Multicast Parameters
) appear next to
