2.2.7 SIP Loudspeaker Amplifier (PoE) Jumpers

JP5

2.2.8 Ethernet Connection

Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
See Figure 2-16 for the jumper locations.
Figure 2-16. Jumper Locations
JP4
See Table 2-5 for the jumper descriptions.
Jumper Description
JP1 Reset—Factory Only
JP2 RTFM (not installed)
JP3 Audio Enable Jumper—Factory Only
JP4 Relay NO/NC (default to NO)—Factory Only
JP5 PoE IEEE 802.3at—Factory Only
See Table 2-6 for details about the SIP Loudspeaker Amplifier (PoE) connection.
Table 2-6. SIP Loudspeaker Amplifier (PoE) Connection
Connection Connection Details
Ethernet Use a RJ 45 cable.
JP3
JP1
Table 2-5. Jumper Descriptions
931236C
SIP Loudspeaker Amplifier (PoE) Setup
SIP Loudspeaker Amplifier (PoE) Jumpers
JP2
Location
SIP Loudspeaker Amplifier
(PoE)
