Table 2-21. Sensor Configuration Parameters (continued)
Web Page Item
Slow Blink
Fast Blink
Sensor Color
Red
Green
Blue
Note You must click on the Save button for the changes to take effect.
Configure the Sensor Configuration Parameters
Description
Strobe will blink ON at the specified brightness for one second
then OFF for one second during the duration of the event.
Strobe will blink ON at the specified brightness then OFF five
times per second during the duration of the event.
Select desired color (only one may be chosen).
The red LED value for Sensor.
The green LED value for Sensor.
The blue LED value for Sensor.
Use this button to preview the strobe flashing behavior for the
Sensor Strobe Settings.
Click the Save button to save your configuration settings.
Note: You need to reboot for changes to take effect.
Click on the Reboot button to reboot the system.
Click on the Toggle Help button to see a short description of
some of the web page items. First click on the Toggle Help
button, and you will see a question mark (
some of the web page items. Move the mouse pointer to hover
over a question mark to see a short description of a specific web
page item.
931236C
SIP Loudspeaker Amplifier (PoE) Setup
) appear next to
