1.8 Typical Warehouse Paging Setup

Loud Speaker Amplifier
Part Numbers: 011404 and 011405
Horn Speaker
Operations Guide
VoIPon www.voipon.co.uk sales@voipon.co.uk Tel: (0)330 088 0195 Fax: +44 (0)1245 808299
Figure 1-3. Typical Warehouse Paging Setup
Two (2) Horn Speakers Attached
Horn Speaker Horn Speaker
Horn to Loud Speaker Amplifier
25' 25'
Typical Example of a 70,000 Square Feet Warehouse Paging Set up
"High Power Mode" with
Horn Speaker
Horn Speaker to Horn Speaker
50'
