GPIO Channel For CR Monitor
•
Enter the GPIO channel number used to trigger On Air lamps or other GPIO functions. This option should
typically be programmed with the same logic channel number for all Show Profiles.
Control Room Headphones Options Section
Source
•
Use the radio buttons to choose the source that will be selected to feed the Control Room headphones upon
Show Profile load.
CR Headphones Master Gain
•
Select the Use: radio button to specify the level of the CR Headphones upon Show Profile load. You may
specify a value between -85 dB and 0 dB.
Signal Mode: CR Headphones
•
Stereo: sets Headphone channel to Stereo.
•
Left / Right: takes the chosen side of the Headphone channel and sends it to both speakers.
•
Sum: Creates a sum of both sides of the Headphone channel and sends the sum to both speakers.
CR Headphones Independent
•
Follow Monitors: CR Headphone source mirrors CR Monitor source selection.
•
Use Headphones Source Select: CR Headphones and CR Monitors are selected independently.
Preview-In-Headphones Mode
•
Off: Sources assigned to Preview bus are not heard in CR Headphones.
•
Stereo: Sources assigned to Preview bus are heard in both sides of the CR Headphones.
•
Split: Sources assigned to Preview bus are summed to mono and heard only in right side of the CR Head-
phones. Regular audio is heard in left side.
CR Headphones EQ Active
•
Bypass: No headphone EQ.
•
Active: Headphones are EQd using the following settings.
© 2017 Axia Audio - Rev 3.2
