Digital Audio Inputs and Outputs

• Reference Level: +4 dBu (-20 dB FSD)
• Impedance: 110 Ohms, balanced (XLR)
• Signal Format: AES-3 (AES/EBU)
• AES-3 Input Compliance: 24-bit with selectable sample rate conversion,
• 32 kHz to 96kHz input sample rate capable.
• AES-3 Output Compliance: 24-bit
• Digital Reference: Internal (network timebase) or external reference 48 kHz,
• +/- 2 ppm
• Internal Sampling Rate: 48 kHz
• Output Sample Rate: 44.1 kHz or 48 kHz
• A/D Conversions: 24-bit, Delta-Sigma, 256x oversampling
• D/A Conversions: 24-bit, Delta-Sigma, 256x oversampling
• Latency <3 ms, mic in to monitor out, including network and processor loop

Frequency Response

• Any input to any output: +0.5 / -0.5 dB, 20 Hz to 20 kHz

Dynamic Range

• Analog Input to Analog Output: 102 dB referenced to 0 dBFS,
• 105 dB "A" weighted to 0 dBFS
• Analog Input to Digital Output: 105 dB referenced to 0 dBFS
• Digital Input to Analog Output: 103 dB referenced to 0 dBFS, 106 dB "A" weighted
• Digital Input to Digital Output: 138 dB
