EQ High Mode
•
Shelf: Selects high-shelf style of EQ application.
•
Peak: EQ is applied to a selected frequency, "notch filter" style.
EQ High/Mid/Low Frequency
•
Select the Use: radio button to set the center frequency of the selected band.
EQ High/Mid/Low Gain
•
Select the Use: radio button to specify an EQ cut or boost between -25 and +15 dB to the selected frequency.
Assign To...
•
On: Assigns fader strip to the specified Program or Aux Send bus upon Show Profile load.
•
Off: Removes fader strip from the specified Program or Aux Send bus upon Show Profile load.
NOTE: Channels may be simultaneously assigned to any combination of Program 1 – 4 and Aux Send 1 – 4
mixing buses.
Aux Send A-B-C-D Pre/Post Fader
•
Pre-Fader: Sends the input source to the selected Aux Send bus before fader gain adjustment.
•
Post-Fader: Sends the input source to the selected Aux Send bus after fader gain adjustment.
Aux Send A-B-C-D Pre/Post ON
•
Pre-ON: Sends the input source to the selected Aux Send bus before the channel's ON/OFF switch.
•
Post-ON: Sends the input source to the selected Aux Send bus after the channel's ON/OFF switch.
Aux Send A-B-C-D Gain
•
Select the Use: radio button to specify any additional gain or cut to be applied to the assigned source before
sending to the selected Aux Send bus.
Noise Gate Status
•
Bypass: Turns off the noise gate feeding the Vocal Compressor section.
•
Active: Turns on the Compressor noise gate.
© 2017 Axia Audio - Rev 3.2
