Individual Headphones Section

Any Fusion input defined as a Microphone source can have a dedicated headphone feed, to facilitate individual
Talkback (IFB) to and from the board operator or other talent. The options below affect this dedicated headphone
feed, if enabled.
Current Source
• If a Microphone source is loaded to this channel, choose the audio source to be fed to its Individual Head-
phone Feed (Backfeed), if desired. Choices include all Program and Aux Send buses, Monitor bus, or a
direct feed from any individual source.
Source For Preset 1 / Preset 2
• Select the audio source assigned to the Preset keys on Axia Talent Headphone accessory panels. Choices
include all Program and Aux Send buses, Monitor bus, or a direct feed from any individual source.
Headphones Master Gain
• Select the Use: radio button to specify the level at which Individual Headphone channel should be fed. You
may specify any level between -85 dB and 0 dB.
Talkback Start Volume Low Limit
Select the Use: radio button to specify the level at which Talkback will be fed to the Individual Headphone
•
channel. You may specify any level between -85 dB and 0 dB.

Record Mode Section

Fusion's Record Mode is a "macro" that allows complex pre-defined operations to take place with a single button
press. The options below define bus assignments for the channel that occur when Record Mode is entered and exited.
Program 1 – 4
• Assign, While In Record Mode: Assigns this channel to the selected Program bus when Record Mode is
active.
• Remove, While In Record Mode: Removes this channel from the selected Program bus until Record
Mode is exited.
• No Change, While In Record Mode: This channel's bus assignments do not change when Record Mode is
active.
