Axia Fusion Installation And User Manual page 20

Using the IEC cable supplied, connect the PowerStation's power supply input to AC mains. Allow PowerStation
to boot; a Setup screen will appear on your monitor.
To set up your PowerStation:
1. Press your keyboard's up-arrow key until the Config IP addr line is highlighted in yellow text.
2. Press the Backspace key to clear values, and use the number keys to enter new values and assign an IP ad-
dress to the PowerStation.
3. Use the arrow keys to move to the Config NetMask and Config Gateway fields, repeat the process to set
the needed values.
4. Use the down-arrow key to move to the Save & Reboot selection. Press the Enter key and the system will
reboot, with the IP address you've entered.
5. Remove the USB keyboard.
Next, connect one end of the 6-pin Molex power cable supplied with your PowerStation to the Power connection
on the board located beneath the overbridge of the Fusion surface.
Tilt overbridge forward (toward faders)
to gain access to connection panel.
© 2017 Axia Audio - Rev 3.2
