CR Headphones EQ High Mode
• Shelf: Selects high-shelf style of EQ application.
• Peak: EQ is applied to a selected frequency, "notch filter" style.
CR Headphones EQ High/Mid/Low Frequency
• Select the Use: radio button to set the center frequency of the selected band.
CR Headphones EQ High/Mid/Low Gain
• Select the Use: radio button to specify an EQ cut or boost between -25 and +15 dB to the selected frequency.

Studio Monitor Options Section

Source
• Use the radio buttons to choose the source that will be selected to feed the Studio Monitor speakers upon
Show Profile load.
Source ID For External Input
• Dropdown box chooses what source will be auditioned when External is chosen from the Studio monitor
assignment list.
Studio Monitor Master Gain
Select the Use: radio button to specify the level of the Studio Monitor speakers upon Show Profile load.
•
You may specify a value between -85 dB and 0 dB.
Studio Monitor Dim Gain
• Select the Use: radio button to specify the amount of attenuation, up to -30 dB, to be applied to the Studio
Monitor channel when Talkback or Preview are in use.
Studio Monitor Muted State Gain
• Select the Use: radio button to specify the amount of attenuation, up to -85 dB, to be applied to the Studio
Monitor channel when muted.
NOTE: Normally, turning a Studio microphone channel ON mutes the Studio Monitor speakers entirely. This
setting allows you to let the monitors to be heard in the Studio at a reduced level, even while Studio Mics
are active.
