Source ID For External Preview
• Dropdown box allows any Source not assigned to a fader to be heard in the Preview channel. Note that this
must be enabled by a pin on the CR Monitor GPIO.
Example: you have an intercom system you wish to feed into the console's Preview channel. To do this, use
the Dropdown box to select the intercom's audio source, then take the GPO from the intercom and use it to
gate open the External Preview input, which would be fed by the intercom audio.
Talkback Gain
• Select the Use: radio button to trim the level of the Talkback channel. You may specify any level of cut or
boost between -30 dB and +10 dB.
Feed To Source Sum Gain
Select the Use: radio button to specify a gain compensation for mono-sum of Talkback audio sources. You
•
may specify between -6 dB and -3 dB of attenuation.
User Buttons GPIO Channel
• If you have a Fusion Expert Monitor Module and wish to control an external device using its 4 User keys,
enter the GPIO Channel Number of the device here.
GPIO Channel For Up Timer Control
• Allows an external device to trigger the Up Timer. Enter the GPIO Channel Number for the desired device.
GPIO Channel For Down Timer Control
• Allows an external device to trigger the Down Timer. Enter the GPIO Channel Number for the desired
device.

Additional Meters Section

Extra Meter 1-2-3-4 Input
• This section allows to you specify meter sources for the "extra" meters that can be displayed in the center
section of Fusion's on-screen display when using an Expert Monitor Module. The selections for each of the
meters are extensive and include all Program, Aux, External and Monitor busses, the Phone and Record
buses, all Fader Channel sources and backfeeds, all VMix inputs, Direct, Sub and Main outputs, as
well as all VMode inputs and outputs.
The extra meters are displayed when the board operator presses the Meter Options key and presses the #6
•
Function knob to select the More Meters option.
