5. Main Monitor Assignments / Confidence Meters let ops know what sources are being heard in the Con-
trol Room and Studio Monitor and Headphone feeds, and in the Preview channel. Adjacent confidence and
set-level meters display show set levels of the physical controls and incoming signals.
6. EXT 1 / EXT 2 Confidence Meters. These meters show the sources of audio assigned to either of the two
External Monitor selection keys, and audio levels of those sources.
7. Profile Window. Displays the name of the active Show Profile.
8. Loudness Meter. Will be displayed under the Show Profile window if enabled.
9. Day/Date/Time Displays. Shows the current date and time in digital format.
© 2017 Axia Audio - Rev 3.2
