Axia Fusion Installation And User Manual page 21

Connect the other end to the Molex connector marked SURFACE on the rear of your PowerStation.
Now, Connect a network patch cable from the board under the Fusion's overbridge to any available port on the
PowerStation's switch.
The next step requires a Web browser on a PC connected to any Ethernet port on your PowerStation's switch
section. Open your browser and enter the IP you assigned to your PowerStation in the URL bar; an authentication
window will appear. Enter the following values:
• Username = user
• Password = <leave blank>
Select "OK" and your Fusion console's control center will be loaded.
1. From the links under the Mix Engine heading, select Network.
2. Click the Install button displayed at the bottom of the Network page. A new page will load.
© 2017 Axia Audio - Rev 3.2
