Sources For External 1 & 2 Section
Source ID For External Input 1 – 2
Use the Dropdown boxes to select sources to be loaded to the External 1 and External 2 Monitor Selection
•
keys when the Show Profile is loaded.
• Board operators can override these selections by pressing and holding the External keys for 5 seconds, then
choosing from the onscreen list of sources.

Control Room Monitor Options Section

Source
• Use the radio buttons to choose the source that will be selected to feed the Control Room Monitor speakers
upon Show Profile load.
CR Monitor Master Gain
• Select the Use: radio button to specify the level of the CR Monitor speakers upon Show Profile load. You
may specify a value between -85 dB and 0 dB.
Signal Mode: CR Monitor
• Stereo: sets Monitor channel to Stereo.
• Left / Right: takes the chosen side of the Monitor channel and sends it to both speakers.
• Sum: Creates a sum of both sides of the Monitor channel and sends the sum to both speakers.
CR Monitor Dim Gain
• Select the Use: radio button to specify the amount of attenuation, up to -30 dB, to be applied to the CR
Monitor channel when Talkback or Preview are in use.
CR Monitor Muted State Gain
• Select the Use: radio button to specify the amount of attenuation, up to -85 dB, to be applied to the CR
Monitor channel when muted.
NOTE: Normally, turning a Control Room microphone channel ON mutes the CR Monitor speakers entirely.
This setting allows you to let the monitors to be heard in the Control Room at a reduced level, even while
CR Mics are active.
