Signal Mode
• Stereo: sets source signal mode to Stereo.
• Left / Right: takes the chosen side of the input signal and sends it to both sides of the stereo channel.
• Sum: Creates a sum of both input channels and sends the sum to both sides of the stereo channel.
Signal Mode Locked
• Unlocked: allows board op to change the Signal Mode from the surface.
• Locked: prevents board op from making changes.
Fader Trim Gain
• Select the Use: radio button to specify a fader trim cut or boost between -25 and +25 dB.
Fader Trim Lock
• Unlocked: allows board op to trim the fader using Channel controls on the console.
• Locked: prevents board op from making changes.
Panorama Position
Select the Use: radio button to Pan the input signal left or right of center.
•
Phase
• Normal: No phase change to input signal.
• Invert Left: Reverses the phase of the left input channel only.
• Invert Right: Reverses the phase of the right input channel only.
• Invert Left and Right: Reverses the phase of both input channels.
EQ Active
• Bypass: Loads the input source with no EQ adjustment.
• Active: Loads the source with EQ active, and applies EQ settings specified in following sections.
