Part 2 – Show Profiles Options
Show Profiles are snapshots that allow you to set up a console the way your talent wants it, then save and recall
those settings with one button press. Up to 99 Show Profiles can be saved per console.
The easiest way to create a Show Profile is to set up your console the way you like it using the controls on the
board itself – then use the Capture Show Profile link found on the Shows screen of your Fusion control center
web page. This will take a snapshot of the entire console – fader assignments, source EQ, mic dynmics, Monitor
assignments, even headphone EQ settings – and save them to a new Show Profile that you can use as-is, or edit later.
When capturing, the settings will be part of the show profile. Many of the options have a retain option which will
not be captured. The retain option permits an existing setting to carry over in the new Show Profile. For example, if
a source is loaded which has a Signal mode of LEFT, the capture process will apply the LEFT setting as part of the
Show Profile. If the Show profile is later edited, so that a different source is loaded, the LEFT option would still be
in place unless altered. In some cases the retain is advised.
There are also some options, such as Record Mode setup, that are not able to be set from the Fusion surface itself,
and must be set up by editing the Show Profile itself. In the next few sections, we'll give you a line-item reference
listing of the options found on each Show Profile screen.

Channel Screen Options

There's a Channel Screen for each of your installed faders and virtual faders that are enabled.Following is a
listing of options presented on each screen.
NOTE: choosing The "Retain Source Setting" option for any item leaves that item unchanged when loading
the Show Profile.

General Controls Section

Source ID
• Dropdown box selects fader's assigned source from saved Source Profiles.
Feed To Source Mode
If the loaded source has a mix-minus, chooses the source for mix-minus creation.
• Auto lets the console choose a mix-minus source automatically.
• Phone, PROGRAM and AUX SEND options let you manually choose the bus to use as the basis of the
mix-minus.
Auto-Start Timer
• Enable: Console interval timer starts when fader ON key is pressed.
• Disable: Timer is unaffected by fader ON key.
