The PowerStation AUX has the same front panel as the PowerStation MAIN, and front-panel indicators are similar.
•
PowerStation AUX has no OK indicator, since there is no main CPU in the AUX.
The LINK indicator lights to show that the I/O board has an active network link.
•
The rear of the PowerStation is divided into three categories: Input/Output, Network switch, and System ports.
The audio inputs on each PowerStation consist of:
•
Two (2) XLR microphone inputs
•
Four (4) RJ45 stereo analog inputs
•
Two (2) RJ45 AES digital audios inputs
•
Six (6) RJ45 stereo analog outputs
•
Two (2) RJ45 AES digital audio outputs
PowerStation MAIN connection panel
PowerStation AUX connection panel
© 2017 Axia Audio - Rev 3.2
