Parameters

3 Parameters
3.1 Main Menu - Operation and Display -
3 3
Group 0
Parameters related to the fundamental functions of the
frequency converter, function of the LCP keys and configu-
ration of the LCP display.
3.1.1 0-0* Basic Settings
0-01 Language
Option:
[0] English
*
[1] Deutsch
[2] Francais
[3] Dansk
[4] Spanish
[5] Italiano
[28] Bras.port
[255] No Text
0-03 Regional Settings
Option:
[0] Interna-
tional
[1] North
America
0-04 Operating State at Power-up
Option:
[0] Resume
*
20
VLT
Function:
Defines the language to be used in the display.
Function:
NOTICE
This parameter cannot be adjusted
while the motor is running.
To meet the needs for different default settings
in different parts of the world, 0-03 Regional
Settings is implemented in the frequency
converter. The selected setting influences the
default setting of the motor nominal frequency.
Sets default value of 1-23 Motor Frequency [50
Hz].
Sets the default value of 1-23 Motor Frequency to
60 Hz.
Function:
Select the operating mode upon reconnection of
the frequency converter to mains voltage after
power down when operating in Hand (local)
mode.
Resumes operation of the frequency converter
maintaining the same local reference and the
same start/stop condition (applied by [Hand On]/
[Off] on the LCP or Hand Start via a digital input
®
HVAC Basic Drive FC 101 Programming Guide
0-04 Operating State at Power-up
Option:
[1] Forced
stop,
ref=old
0-06 GridType
Option:
[0] 200-240V/50Hz/IT-grid
[1] 200-240V/50Hz/Delta
[2] 200-240V/50Hz
[10] 380-440V/50Hz/IT-grid
[11] 380-440V/50Hz/Delta
[12] 380-440V/50Hz
[20] 440-480V/50Hz/IT-grid
[21] 440-480V/50Hz/Delta
[22] 440-480V/50Hz
[30] 525-600V/50Hz/IT-grid
[31] 525-600V/50Hz/Delta
[32] 525-600V/50Hz
[100] 200-240V/60Hz/IT-grid
[101] 200-240V/60Hz/Delta
[102] 200-240V/60Hz
[110] 380-440V/60Hz/IT-grid
[111] 380-440V/60Hz/Delta
[112] 380-440V/60Hz
[120] 440-480V/60Hz/IT-grid
[121] 440-480V/60Hz/Delta
[122] 440-480V/60Hz
[130] 525-600V/60Hz/IT-grid
MG18B302 - Rev. 2013-09-02
Function:
as before the frequency converter was powered
down.
Uses saved reference [1] to stop the frequency
converter but at the same time retain the local
speed reference in memory before powering
down. After mains voltage is reconnected and
after receiving a start command (pressing [Hand
On] key or using her Hand Start command via a
digital input) the frequency converter restarts
and operates at the retained speed reference.
Function:
Select the grid type of the supply
voltage/frequency.
NOTICE
Not all choices are supported
in all power sizes.
IT grid is a supply mains, where
there are no connections to
ground.
Delta is a supply mains where the
secondary part of the transformer
is delta connected and one phase
is connected to ground.
