Parameters
5-53 Term. 29 High Ref./Feedb. Value
Range:
50 [-4999 - 4999 ]
*
Size [-999999.999 -
related 999999.999
*
ReferenceFeed-
backUnit]
3.6.6 5-9* Bus Controlled
This parameter group selects digital and relay outputs via
a fieldbus setting.
5-90 Digital & Relay Bus Control
Range: Function:
0 [0 - This parameter holds the state of the digital
*
0xFFFFFFFF ] outputs and relays that is controlled by bus.
A logical '1' indicates that the output is
high or active.
A logical '0' indicates that the output is low
or inactive.
Bit 0 - 3 Reserved
Bit 4 Relay 1 output terminal
Bit 5 Relay 2 output terminal
Bit 6 - 23 Reserved
Bit 24 Terminal 42 Digital Output
Bit 25 Terminal 45 Digital Output
Bit 26 - 31 Reserved
Table 3.5 Bit Functions
®
VLT HVAC Basic Drive FC 101 Programming Guide
Function:
Enter the high reference value
[RPM] for the motor shaft
speed and the high feedback
value, see also 5-58 Term. 33
High Ref./Feedb. Value. Select
terminal 29 as a digital input
(5-02 Terminal 29 Mode = [0]
input (default) and
5-13 Terminal 29 Digital Input =
applicable value).
