Danfoss VLT HVAC Basic Drive FC 101 Programming Manual page 74

Parameters
16-61 Terminal 53 Setting
Option:
[0] Current mode
*
3 3
[1] Voltage mode
16-62 Analog Input AI53
Range:
1 [0 - 20 ]
*
16-63 Terminal 54 Setting
Option:
[0] Current mode
*
[1] Voltage mode
16-64 Analog Input AI54
Range:
1 [0 - 20 ]
*
16-65 Analog Output AO42 [mA]
Range:
0 mA [0 - 20
*
mA]
16-66 Digital Output
Range: Function:
0 [0 - View the binary value of all digital outputs.
*
15 ]
Definition:
X: Not used
0: Low
1: High
XX
X0
X1
0X
0
1
1X
10
11
Table 3.9 Binary Value of Digital Outputs
72
VLT
Function:
View the setting of input terminal 53.
Current = 0; Voltage = 1.
Function:
View the actual value at input 53.
Function:
View the setting of input terminal 54.
Current = 0; Voltage = 1.
Function:
View the actual value at input 54.
Function:
View the actual value at output 42 in mA.
The value shown reflects the selection in
6-90 Terminal 42 Mode and 6-91 Terminal 42
Analog Output.
None used
Terminal 42 not used, Terminal 45
low
Terminal 42 not used, Terminal 45
High
Terminal 42 low, Terminal 45 not
used
Terminal 42 low, Terminal 45 low
Terminal 42 low, Terminal 45 high
Terminal 42 high, Terminal 45 not
used
Terminal 42 high, Terminal 45 low
Terminal 42 high, Terminal 45 high
®
HVAC Basic Drive FC 101 Programming Guide
16-67 Pulse Input #29 [Hz]
Range:
0 [0 - 130000 ] View the actual frequency rate on terminal
*
16-71 Relay Output [bin]
Range:
0 [0 -
*
65535 ]
16-72 Counter A
Range:
0 [-32768 -
*
32767 ]
16-73 Counter B
Range:
0 [-32768 -
*
32767 ]
16-79 Analog Output AO45
Range:
0 mA
*
3.12.6 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control
words.
16-86 FC Port REF 1
Range:
0 [-32768 - 32767 ] View the last received reference from the
*
MG18B302 - Rev. 2013-09-02
Function:
29.
Function:
View the setting of the relay.
Bits definition:
Bit 0~2 Unused
Bit 3 Relay 02
Bit 4 Relay 01
Bit 5~15 Unused
Table 3.10 Relay Setting
Function:
View the present value of Counter A. Counters
are useful as comparator operands, see
13-10 Comparator Operand.
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital Inputs)
or by using an SLC action (13-52 SL Controller
Action).
Function:
View the present value of Counter B. Counters are
useful as comparator operands (13-10 Comparator
Operand).
The value can be reset or changed either via
digital inputs (parameter group 5-1* Digital Inputs)
or by using an SLC action (13-52 SL Controller
Action).
Function:
[0 - 20 mA]
Function:
FC port.
