Parameters
8-53 Start Select
Option: Function:
[2] Logic Activates Start command via the serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic OR Activates Start command via the serial
*
communication port OR via one of the digital
inputs.
8-54 Reversing Select
Option: Function:
Select control of the frequency converter reverse
function via the terminals (digital input) and/or
via the serial communication port.
NOTICE
This parameter is active only when
8-01 Control Site is set to [0] Digital and
control word.
[0] Digital Activates Reverse command via a digital input.
*
input
[1] Bus Activates Reverse command via the serial
communication port.
[2] Logic Activates Reverse command via the serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic OR Activates Reverse command via the serial
communication port OR via one of the digital
inputs.
8-55 Set-up Select
Option: Function:
Select control of the frequency converter set-up
selection via the terminals (digital input) and/or
via the serial communication port.
NOTICE
This parameter is active only when
8-01 Control Site is set to [0] Digital and
control word.
[0] Digital Activates the set-up selection via a digital input.
input
[1] Bus Activates the set-up selection via the serial
communication port.
[2] Logic Activates the set-up selection via the serial
AND communication port, AND additionally via one of
the digital inputs.
[3] Logic OR Activate the set-up selection via the serial
*
communication port OR via one of the digital
inputs.
®
VLT HVAC Basic Drive FC 101 Programming Guide
8-56 Preset Reference Select
Option:
[0] Digital
input
[1] Bus
[2] Logic
AND
[3] Logic OR
*
3.8.4 8-7* BACnet
8-70 BACnet Device Instance
Range:
1 [0 - 4194303 ] Enter a unique ID number for the BACnet
*
8-72 MS/TP Max Masters
Range:
127
*
8-73 MS/TP Max Info Frames
Range:
1 [1 - 65534 ] Define how many info/data frames the device
*
8-74 "I am" Service
Option:
[0] Send at
*
power-up
[1] Continuously
8-75 Intialisation Password
Range:
admin
*
MG18B302 - Rev. 2013-09-02
Function:
Select control of the frequency converter Preset
Reference selection via the terminals (digital
input) and/or via the serial communication port.
Activates Preset Reference selection via a digital
input.
Activates Preset Reference selection via the
serial communication port.
Activates Preset Reference selection via the
serial communication port, AND additionally via
one of the digital inputs.
Activates the Preset Reference selection via the
serial communication port OR via one of the
digital inputs.
Function:
device.
Function:
[0 - 127 ] Define the address of the master which holds
the highest address in this network.
Decreasing this value optimises polling for the
token.
Function:
is allowed to send while holding the token.
Function:
Select whether the device should send the
"I-Am" service message only at power-up or
continuously with an interval of approx. 1
min.
Function:
[1 - 1 ] Enter the password needed for execution of
Drive Re-initialisation.
