Danfoss VLT HVAC Basic Drive FC 101 Programming Manual page 63

Parameters
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the logic
rule.
[31] SL Time-out 1 Use the result of timer 1 in the logic
rule.
[32] SL Time-out 2 Use the result of timer 2 in the logic
rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule
(High = TRUE).
[34] Digital input DI19 Use the value of DI19 in the logic rule
(High = TRUE).
[35] Digital input DI27 Use the value of DI27 in the logic rule
(High = TRUE).
[36] Digital input DI29 Use the value of DI29 in the logic rule
(High = TRUE).
[39] Start command This logic rule is TRUE if the frequency
converter is started by any means
(either via digital input, or other).
[40] Drive stopped This logic rule is TRUE if the frequency
converter is stopped or coasted by any
means (either via digital input, or
other).
[42] Auto Reset Trip This logic rule is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
[50] Comparator 4 Use the result of comparator 4 in the
logic rule.
[51] Comparator 5 Use the result of comparator 5 in the
logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the
logic rule.
®
VLT HVAC Basic Drive FC 101 Programming Guide
13-40 Logic Rule Boolean 1
Array [6]
Option:
[61] Logic rule 5
[70] SL Time-out 3
[71] SL Time-out 4
[72] SL Time-out 5
[73] SL Time-out 6
[74] SL Time-out 7
[83] Broken Belt
13-41 Logic Rule Operator 1
Option:
[0]
*
[1]
[2]
[3]
[4]
[5]
[6]
[7]
[8]
13-42 Logic Rule Boolean 2
Array [6]
Option:
[0] False
*
[1] True
[2] Running
[3] In range
[4] On reference
[7] Out of current range
[8] Below I low
[9] Above I high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
MG18B302 - Rev. 2013-09-02
Function:
Use the result of logic rule 5 in the
logic rule.
Use the result of timer 3 in the logic
rule.
Use the result of timer 4 in the logic
rule.
Use the result of timer 5 in the logic
rule.
Use the result of timer 6 in the logic
rule.
Use the result of timer 7 in the logic
rule.
A broken belt condition has been
detected. This function must be
enabled in 22-60 Broken Belt Function.
Disabled
AND
OR
AND NOT
OR NOT
NOT AND
NOT OR
NOT AND NOT
NOT OR NOT
Function:
Select the second boolean (TRUE or
FALSE) input for the selected logic
rule.
See 13-40 Logic Rule Boolean 1 for
further descriptions of choices and
their functions.
