13-01 Start Event
Option:
[27] Logic rule 1
[28] Logic rule 2
3 3
[29] Logic rule 3
[33] Digital input
DI18
[34] Digital input
DI19
[35] Digital input
DI27
[36] Digital input
DI29
[39] Start command
*
[40] Drive stopped
[42] Auto Reset Trip
[50] Comparator 4
[51] Comparator 5
[60] Logic rule 4
[61] Logic rule 5
[83] Broken Belt
13-02 Stop Event
Option:
[0] False
[1] True
[2] Running
58
®
VLT HVAC Basic Drive FC 101 Programming Guide
Function:
Use the result of logic rule 1 in the
logic rule.
Use the result of logic rule 2 in the
logic rule.
Use the result of logic rule 3 in the
logic rule.
Use the value of DI18 in the logic rule
(High = TRUE).
Use the value of DI19 in the logic rule
(High = TRUE).
Use the value of DI27 in the logic rule
(High = TRUE).
Use the value of DI29 in the logic rule
(High = TRUE).
This event is TRUE if the frequency
converter is started (either via digital
input, field bus or other).
This event is TRUE if the frequency
converter is stopped or coasted (either
via digital input, fieldbus or other).
This event is TRUE if the frequency
converter is tripped (but not trip-
locked) and an Automatic Reset is
issued.
Use the result of comparator 4 in the
logic rule.
Use the result of comparator 5 in the
logic rule.
Use the result of logic rule 4 in the
logic rule.
Use the result of logic rule 5 in the
logic rule.
A broken belt condition has been
detected. This function must be
enabled in 22-60 Broken Belt Function.
Function:
Select the condition (TRUE or FALSE)
which deactivates the Smart Logic
Controller.
Enters the fixed value of FALSE in the
logic rule.
Enters the fixed value TRUE in the
logic rule.
See 13-01 Start Event for further
description.
MG18B302 - Rev. 2013-09-02
13-02 Stop Event
Option: Function:
[3] In range See 13-01 Start Event for further
description.
[4] On reference See 13-01 Start Event for further
description.
[7] Out of current See 13-01 Start Event for further
range description.
[8] Below I low See 13-01 Start Event for further
description.
[9] Above I high See 13-01 Start Event for further
description.
[16] Thermal warning See 13-01 Start Event for further
description.
[17] Mains out of See 13-01 Start Event for further
range description.
[18] Reversing See 13-01 Start Event for further
description.
[19] Warning See 13-01 Start Event for further
description.
[20] Alarm (trip) See 13-01 Start Event for further
description.
[21] Alarm (trip lock) See 13-01 Start Event for further
description.
[22] Comparator 0 Use the result of comparator 0 in the
logic rule.
[23] Comparator 1 Use the result of comparator 1 in the
logic rule.
[24] Comparator 2 Use the result of comparator 2 in the
logic rule.
[25] Comparator 3 Use the result of comparator 3 in the
logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the
logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the
logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the
logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the
logic rule.
[30] SL Time-out 0 Use the result of timer 0 in the logic
rule.
[31] SL Time-out 1 Use the result of timer 1 in the logic
rule.
[32] SL Time-out 2 Use the result of timer 2 in the logic
rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule
(High = TRUE).
