Table 99. Fsmc_Tcrx Bit Fields - ST STM32F101xx Reference Manual

RM0034
Table 98.
Bit No.
11
10
9
8
7
6
5-4
3-2
1
0
Table 99.
Bit No.
27-24
23-20
19-16
15-8
7-4
3-0
FSMC_BCRx bit fields (continued)
Bit name
WAITCFG to be set according to memory
WRAPMOD to be set according to memory
WAITPOL to be set according to memory
BURSTEN 0x1
FWPRLVL Set to protect memory from accidental write access
FACCEN Set according to memory support
MWID As needed
MTYP 0x1 or 0x2
MUXEN As needed
MBKEN 0x1
FSMC_TCRx bit fields
Bit name
DATLAT Data latency
0x0 to get CLK = HCLK (not supported)
CLKDIV
0x1 to get CLK = 2 × HCLK
BUSTURN no effect
DATAST no effect
ADDHLD no effect
ADDSET no effect
Flexible static memory controller (FSMC)
Value to set
Value to set
427/959
